ESP32-P4 PICO Development Board with MIPI DSI 10.1-inch Display, CSI Camera, and Audio Speaker

$67.9

Brand:SpotPear
SKU:020806700000
Date:2025-08-07 17:31
No:
In Stock

ESP32-P4 Development Board A high-performance development board based on ESP32-P4. Equipped with a high-performance RISC-V 32-bit dual-core and single-core processor MCU. Provides a rich set of human-computer interaction interfaces.

ESP32-P4 Development Board

High-performance development board based on ESP32-P4

Rich human-computer interaction interface


Development Board Introduction

This product is a multimedia development board based on the ESP32-P4. It offers a rich set of human-computer interaction interfaces, including MIPI-CSI (with integrated image signal processor), MIPI-DSI, SPI, I2S, I2C, LED PWM, MCPWM, RMT, ADC, UART, and TWAI. It also supports USB OTG 2.0 HS and features a 40-pin GPIO expansion header compatible with some Raspberry Pi Pico expansion boards, enabling a wider range of applications. The ESP32-P4 utilizes a 400MHz dual-core RISC-V processor, supports up to 32MB of PSRAM, and includes peripherals such as USB 2.0, MIPI-CSI/MIPI-DSI, and H.264 encoding, meeting the needs of low-cost, high-performance, and low-power multimedia development. Furthermore, the ESP32-P4 integrates a digital signature peripheral and a dedicated key management unit to ensure data and operational security. ESP32-P4-Pico is designed for high-performance and high-security applications, meeting the needs of embedded systems in human-computer interaction, edge computing, and I/O expansion.。
Main features:

  • High-performance MCUs with RISC-V 32-bit dual-core and single-core processors
  • 128KB HP ROM、16KB LP ROM、768KB HP L2MEM、32KB LP SRAM、8KB TCM
  • Powerful image and voice processing capabilities, including image and voice processing interfaces such as JPEG codec, pixel processing accelerator (PPA), image signal processor (ISP), and H264 video encoder
  • 32MB PSRAM is stacked inside the chip package, and 32MB Nor Flash is integrated externally
  • Common peripheral interfaces such as MIPI-CSI, MIPI-DSI, USB 2.0 OTG, SDIO 3.0, SD card slot, microphone and speaker terminals are brought out on the board
  • 2 × 20 pin headers are provided on the board, leading to 27 remaining programmable GPIOs
  • Security mechanisms: secure boot, Flash encryption, hardware encryption accelerator, and hardware random number generator. Hardware access protection is also supported to implement access rights management (APM) and privilege separation.

Package Selection

Examples of meal combinations

DSI capacitive touch screen

IPS fully laminated tempered glass panel with a 178° wide viewing angle and 10-point touch support for clear images and an excellent visual experience.


Screen model
10.1-DSI-TOUCH-A
Resolution
800 × 1280 (H × V)
Communication interface
MIPI-DSI (2-lane)
brightness
400cd/m² (Support customized 1000cd/m² high brightness version)
touch chip
GT9271
Dimensions
147.0 × 239.0 (mm)
Display size
135.36 × 216.58 (mm)
Pixel size
0.1692 (H) × 0.1692 (V) (mm)
Contrast
800:1
Operating temperature
0℃ ~ 60℃

(Only Development Board Package B comes with a screen)

Raspberry Pi Camera Model B

5 megapixels | Manual focus

Compatible with Raspberry Pi series motherboards


Photosensitive chipOV5647CMOS size1/4 inch
Pixel5 millionapertureF2.0
focal length6mmDiagonal field of view60.6°
Infrared night visionNot supportedFocusing methodManual focus

The pictures are for display only. Please refer to the configuration list for detailed configuration.

Highly integrated, powerful performance

The development board uses the ESP32-P4 chip and has 32MB of onboard Nor Flash.


Resource Introduction


  1. ESP32-P4NRW32

    ESP32-P4 with 32MB PSRAM

  2. 32MB Nor Flash
  3. Display interface

    MIPI-DSI (2-lane), compatible with 5/7/8/10.1-inch DSI displays

  4. Camera interface

    MIPI-CSI (2-lane), can connect to cameras such as OV5647

  5. Type-C port

    Can be used for power supply and program burning

  6. Chip Microphone
  1. Speaker jack

    MX1.25 2P connector, supports 8Ω 2W speakers

  2. 4-pin USB port

    USB OTG 2.0 High Speed interface

  3. BOOT button

    Press when powering on or resetting to enter download mode

  4. RST button

    Reset button

  5. Power indicator
  6. SD card slot

    SDIO 3.0 interface protocol



Pin Definition


Product size
