Where is the documentation about this module? schematics, PINs available, eagle file, code example ?

2025-12-10 05:46:19 Ask

To know the development possibilities of this module is important the documentation about :

- Schematics

- PINs available

- Eagle file

- List of materials

- Code example

- Support for the debug board

But where is published ?

Thanks for your attention and soon reply before to confirm an order,

ESP32 S3 LVGL

APost Reply

Like0| report

3answers

SpotPearGueste93f8

Answer time:2025-12-10 09:12:30

https://spotpear.com/wiki/ESP32-S3-1.5-inch-Round-Rotary-OLED-TouchScreen-Knob-Display-466x466.html#4.%20Schematic

This is the user manual corresponding to the product. Please refer to it, and if you have any questions, contact tech-support@spotpear.com.

Like0

report

SpotPearGuest48401

Answer time:2025-12-10 21:23:41

https://spotpear.com/wiki/ESP32-S3-1.5-inch-Round-Rotary-OLED-TouchScreen-Knob-Display-466x466.html

ALL documentation On This weblink

which include pin schematics, PIN layouts, and code examples

Like0

report

SpotPearGuest0cb07

Answer time:2025-12-11 00:59:43

Great project! Could you please share the documentation for this module? I’m looking for schematics, PIN details, any available Eagle files, and a basic code example to get started. Thanks!

Like0

report

APost Reply

Where is the documentation about this module? schematics, PINs available, eagle file, code example ?

ESP32 S3 Development Board 1.5 inch Round Rotary OLED TouchScreen Smart Knob Display 1.5inch Display 466x466 LVGL for Arduino
